HHO Truck Kit HS 16 000-24V Nano Mini Plug N Play
Hydrogen system specially designed for American trucks with Diesel engines up to 16 000cc engine displacement and a 24V charging system.
Plug N Play – Easy to install and fully automated system, which saves up to 25% fuel and reduces emissions up to 78%
- Additional information
Hydrogen system HS 16 000-24V is designed for American trucks with a 24V charging system. This is a Plug’N Play system, which is easy to install behind the cabin in any diesel truck. Does not need any engine modifications or tampering of the fuel management or electrical systems.
No computer software programming, setting up, timing or mixture adjustments are required on the vehicle.
This Hydrogen system has a built-in automatic start & stop function, automatic safety shutdown, and regulates the production of Oxy-hydrogen gas based on the RPMs of the engine.
Easy & Quick installation
High quality components
Fully automated Ampere limiter built-in
No run-on after shutdown
Adjustable power ranges
Water level sensor
More than 3000 km. with one refill
Equipped with Dynamic PWM’s to control the amperes and production of HHO gas depending on the engine RPMs. There is a LED indicator installed near the dashboard to indicate when the reservoir needs to be refilled with electrolyte.
Most trucks make approximately 15 000km. per month which at minimum fuel saving 2 liters per 100km is equal to 450L. of diesel fuel saving!
Technical Data of the System
Dimensions of the system:
in centimeters: H 52 cm x W 40 cm x D 25 cm
in inches: H 20.5 inch x W 16 inch x D 10 inch
Weight: 28 kg.
Voltage: 24 – 29 VDC (from vehicles battery)
Material: Stainless steel INOX 316 Ti
Configuration of the plates: + NNNNNNNN – NNNNNNNN +
(+ positive, N-neutral, – negative)
Amperage: 3 to 16 Amp Automatic
Working surface: 4205 sq. cm
Capacity: up to 3 liters of gas per minute
The required ratio of the electrolyte (water-KOH): 5%-15%
The Plug N Play system includes:
#HHO Dry cell -1 pc.
#HHO tank/reservoir 8 liter – 2 pc.
#HHO bubbler – 1 pc.
tubing – 6m.
Red 6 sq.mm. – 3.00 m
Black 6 sq.mm. – 2.00 m
Blue 1.5 sq.mm. – 3.00 m
fuse and fuse holder – 30 amps -2pc.
Inlet gas connector – 1pc.
All electrical connectors
Installation instruction + scheme
Instructions for use
|Dimensions||44 × 29 × 54 cm|
